ISG2410WK1-8-FS - Shrink Fit Machine with Graphical Display
| Control Panel: Graphical |
| Clamping Range: 3 - 20mm |
| Max. Tool Length: 400mm @ HSK-A63 |
| Max. Cooling Length: 200mm @ HSK-A63 |
| Cooling Type: Liquid Cooling with Drying, Geometry Independent |
| Cooling Time: 30 sec |
| Power Requirements: 400V / 16A (3 Phase + Neutral + Earth) |
| Power Consumption: 8 kW |
| Dimensions: 800 x 560 x 1720 mm |
| Includes: Protective Gloves, Operation Manual, Coil 1 (3-32mm), 4 Pole Discs, 1000ml of Cooling and Corrosion Protection |
| Does Not Include: Tool Carrier |
The ISG2410WK1-FS is a fully automatic shrink fit machine designed for rapid, hands-free operation with liquid cooling, integrated drying and geometry-independent performance. It handles tool shanks from 3 mm to 20 mm and lengths up to 400 mm (HSK-A63), achieving typical cycle times of around 20–30 seconds. Combining automation, precision and safety, the system delivers consistent shrinking results while minimising operator involvement. Its advanced cooling and drying process shortens turnaround between tools, making it well suited to demanding, high-volume production environments.
Key Benefits
• Fully automatic shrink fit process enhances safety and consistency
• Rapid liquid cooling and integrated drying support high productivity
• Stable cycle times with reduced variability in intensive use
Internal Reference:
5110995
