ISG3430TLK-WS -Shrink Fit Machine with Graphical Display
| Control Panel: Graphical |
| Clamping Range: 3 - 32mm |
| Max. Tool Length: 450mm @ HSK-A63 |
| Max. Cooling Length: 200mm @ HSK-A63 |
| Cooling Type: Air Cooled |
| Cooling Time: 300 sec |
| Power Requirements: 400V / 16A (3 Phase + Neutral + Earth) |
| Power Consumption: 11 kW |
| Dimensions: 780 x 535 x 970 mm |
| Includes: Protective Gloves, Operation Manual, Coil 1 (3-32mm), 4 Pole Discs |
| Does Not Include: Tool Carrier or Cooling Adapter |
The ISG3430TLK series delivers high‑performance tabletop shrink fitting with efficient air cooling and rapid cycle times for tool shanks from 3 mm to 32 mm and lengths up to 450 mm. It provides the reliability and repeatability required in busy workshop environments, while semi-automatic tool movement reduces operator effort and supports consistent processes. Its intuitive control interface streamlines per-tool setup and process monitoring, and the ergonomic design with integrated cooling helps maintain stable productivity over long shifts.
This model features quick-change coil system, designed for workshops that switch between tool sizes regularly.
Key Benefits
• Semi-automatic operation reduces manual handling and speeds up cycles
• Efficient air cooling supports repeatable shrinking for a wide tool range
• Compact tabletop format with professional-grade performance
