ISG3430TLK-11-WS-BIL - Shrink Machine with Graphical Display
| Control Panel: Graphical |
| Clamping Range: 3 - 32mm |
| Max. Tool Length: 450mm @ HSK-A63 |
| Max. Cooling Length: 200mm @ HSK-A63 |
| Cooling Type: Air Cooled |
| Cooling Time: 300 sec |
| Power Requirements: 400V / 16A (3 Phase + Neutral + Earth) |
| Power Consumption: 11 kW |
| Dimensions: 780 x 535 x 970 mm |
| Includes: Protective Gloves, Operation Manual, Coil 1 (3-32mm), 4 Pole Discs |
| Does Not Include: Tool Carrier or Cooling Adapter |
The ISG3430TLK series, available in both graphical and touch display versions, delivers high-performance tabletop shrink fitting with efficient liquid cooling and rapid cycle times. Designed for tool shanks from 3 mm to 32 mm and lengths up to 450 mm, it provides the reliability and repeatability needed in busy workshop environments. Its intuitive interface streamlines per-tool setup and process control, while the ergonomic design and advanced cooling system help maintain consistent productivity.
Key Benefits
• Choice of graphical or touch display for intuitive control
• Efficient liquid cooling enhances productivity
• Tabletop flexibility with professional-grade performance
Internal Reference:
5102054
